Pre Engineered Structure

Name: Pre Engineered Structure
Brand: Cladding Project Pvt Ltd
Price: 92.0 INR
Availability: InStock

Price 92.0 INR/ Metric Ton

Get a Price/Quote

MOQ : 100 Metric Tons

Pre Engineered Structure Specification

Window Material
Aluminum or PVC

Insulation
PUF or Glasswool insulation panels

Connection
Bolt Connected or Welded

Dimension (L*W*H)
As per requirement (typically 20m x 30m x 8m)

Life Span
25-30 Years

Open Style
Sliding, Hinged

Wall Materials
Insulated Sandwich Panels or Galvanized Steel Sheet

Door Material
Steel or Aluminum

Material
High Strength Structural Steel (IS 2062 / ASTM A572)

Roof Material
Galvanized Steel Sheet or Pre-painted Galvalume Sheet

Door
Other

Thickness Of Wall Panel
50-100 mm

Window
Single/Double Glazed

Window Style
Fixed or Sliding

Floor Material
Concrete or Chequered Plate

Floor Load
Up to 500 kg/m (customizable)

Roof Dead Load
15-30 kg/m

Roof Live Load
0.5-1.0 kN/m

Earthquake Intensity
Resistant up to Zone IV/V

Color
Standard Industrial Grey/Blue (custom available)

Use
Warehouse, Factory, Workshop, Industrial Shed

Accessories
Ridge Ventilators, Turbo Vents, Skylights, Gutters & Downpipes

Fire Resistance
Non-combustible building materials

Purlins & Girts
Cold Formed C/Z Purlins and Girts

Paint Finish
Epoxy Primer with Polyurethane Topcoat

Roof Slope
1:10 Standard (Customizable)

Service Doors
Roll Up Shutters, Personnel Doors

Surface Treatment
Hot Dip Galvanized/Primed & Painted

Frame Type
Primary Framing: Portal Frames (Columns and Rafters)

Maintenance
Minimal requirement, easy cleaning

Noise Reduction
Optional Acoustic Insulation

Wind Resistance
Designed up to 180 km/h

Construction Speed
Rapid, 6-8 weeks for standard structure

Cladding Type
Profiled Sheeting with Anti-corrosive Coating

Rainwater Goods
Pre-fabricated Galvanized Gutters

Pre Engineered Structure Trade Information

Minimum Order Quantity
100 Metric Tons

Supply Ability
25000 Metric Tons Per Year

Delivery Time
2 Days

About Pre Engineered Structure

Our Pre Engineered Structure, which is mainly designed by us by using the high level of techniques, is preferred in different sectors. We use the best in class grade of steel material for fabricating this type of structure. It is widely demanded among the people as it can face the changing weather conditions such as wind storm. The Pre Engineered Structure we offer provides the customers the ease to transportation and installation because of being light in its weight.

Specification

Location/City	Pan India
Type Of Property	Any
Service City	Any
Model Name/Number	Customized
Surface Finished	Customized
Features	Customized

Primary Framing and Structural Integrity

Engineered with portal frames using columns and rafters built from high-strength steel, the structure delivers exceptional load-bearing capability and seismic resistance up to Zone IV/V. All connections are bolt connected or welded, ensuring a rigid and stable framework that endures heavy industrial use and environmental stresses.

Advanced Cladding and Finish

Walls and roofs are clad in profiled steel or insulated sandwich panels, treated with anti-corrosive coatings. Surfaces undergo hot-dip galvanization and are finished with epoxy primer and polyurethane topcoat, protecting against harsh climates while maintaining visual appeal. The standard industrial colors can be customized to meet specific project requirements.

Ventilation, Drainage, and Accessories

The structure includes advanced rainwater goods like pre-fabricated galvanized gutters and downpipes. Ventilation is enhanced with ridge ventilators and turbo vents, while skylights provide natural daylight. Rolling shutters, personnel doors, and durable windows (aluminum or PVC) complete the system, supporting operational efficiency.

Rapid Construction and Low Maintenance

Our modular approach enables fast on-site assembly, reducing project timelines to 68 weeks for standard sizes. Minimal maintenance and easy cleaning are achieved through corrosion-resistant finishes and robust materials, ensuring long-term cost savings and building reliability.

FAQs of Pre Engineered Structure:

Q: How are the primary framing and roof structures designed for stability and durability?

A: The structure uses portal frames made from high-strength structural steel (IS 2062 / ASTM A572), with cold-formed C/Z purlins and girts. These components are either bolt connected or welded, providing strong support and resistance against wind speeds up to 180 km/h and earthquake zones IV/V.

Q: What cladding and insulation options are available for these structures?

A: You can choose profiled galvanized steel sheeting or insulated sandwich panels (PUF or Glasswool) for both roofs and walls. Anti-corrosive coatings and polyurethane finishes are applied to enhance longevity, while acoustic insulation and various thickness options help improve comfort and efficiency.

Q: When can I expect the completion of my pre-engineered building?

A: Standard structures are completed within 68 weeks after finalizing specifications, thanks to factory prefabrication and streamlined on-site assembly. Customization may slightly adjust timelines depending on required modifications and scale.

Q: Where can these pre-engineered buildings be used?

A: They are ideal for industrial and commercial purposes including warehouses, factories, workshops, and industrial sheds. The flexibility in dimensions and configurations makes them suitable for various operational needs across different industries.

Q: How is maintenance managed, and what benefits does the design offer?

A: Thanks to advanced protective finishes, hot-dip galvanization, and minimalistic design, the structure requires only basic cleaning and routine checks. This reduces long-term maintenance costs and downtime, making it both practical and economical.

Q: What are the customization options regarding dimensions, doors, windows, and finish?

A: Clients can specify building size, roof slope, wall and roof materials, door and window styles, colors, and insulation types. Options include roll-up shutters, sliding or fixed windows, and single/double glazing for varied operational requirements.

Q: What is the floor load capacity and suitable floor materials for these buildings?

A: Floors can be constructed with reinforced concrete or chequered plates, supporting up to 500 kg/m (customizable for higher loads), accommodating heavy machinery, equipment, and storage needs commonly found in industrial settings.
